Super Heavy Duty 3m Remote Control Automatic Swing Door Operators
Model：OW-1000Max Door Weight：1000kg
Max Door Width：3000mm
- Product Details
- PRODUCTS ADVANTAGE
Anhui Haida Door Control Equipment Co., Ltd. is one of the most experienced manufacturers and suppliers of super heavy duty 3m remote control automatic swing door operators in China. With abundant experience, we warmly welcome you to wholesale bulk high quality products in stock here and get free sample from our factory. Customized orders are welcome.
FEATURES
Ultra-quiet operation: precision internal structure + imported gears.
Intelligent control: microcomputer processing system, fast execution of various commands
200m remote control: super long remote control distance, up to 200m in open area.
Bounce back when encountering obstacles: automatically return when opening to avoid pinching.
Super hardcore eight levels of waterproof: six waterproof protection layers of protection, even if submerged in water can also run for a long time.
1 ton load-bearing: Automatic swing door opener self-created brand, cumulative sales of nearly 200,000 units of electric floor springs, with a number of real estate cooperation, major projects recommended to use. In 2007, the first electric floor spring was developed in China. 2021, the first extra heavy duty electric floor spring was developed in China.
SPECIFICATIONS
|
Suitable for door width |
Up to 3000MM |
|
Suitable for door weight |
Up to 1000KG |
|
Work Procedures |
Power on and close the door - lock - receive the door opening signal open - buffer - stop the door - delay - close the door - buffer - stop the door - lock |
|
Opening angle |
80°-130° (Special Customized) |
|
Open direction |
One-way open |
|
On hold time |
1 - 20 seconds adjustable |
|
Opening speed |
4 - 10 seconds adjustable |
|
Buffering speed |
Adjustable |
|
Closing speed |
4 - 10 seconds adjustable |
|
Remote control function |
Open, half-open, normally open, locked function |
|
Auto overload protection |
Yes, bounce back when encountering resistance (overload) |
|
Close and stop the door position |
External travel limit |
|
Closing buffer function |
Yes, distance adjustable |
|
Left and right door distinction |
No distinction between left and right doors |
|
Control electric lock function |
12V.1A power supply to the external electric lock after the door is closed (Energized to lock) |
|
Power supply |
110v--230V |
|
Input power |
Static 6W, max 100W |
|
Mainframe Dimension |
L459*W214*H110 |
|
Dual door communication function |
Available: Plug-in |
|
Back-up power function |
Optional |
|
Whole machine torque |
Max. 1000N/M(Adjustable) |
|
Shield signal setting |
Available |
|
Active anti-pinch |
Safety light or safety light curtain |
|
Passive anti-pinch |
Bouncing function when blocked(2s) |
Why Choose Us
1. The world's biggest floor spring manufacturer in China.Daily production over 15,000PCS
2. The factory has three production bases located in ZHEJIANG, ANHUI, JIANGSU three provinces. The area covers 72,000 square meters.
3. Over 33 years of producing experience. Ripe production process.
4. Impeccable testing system covered from raw material, components,semi-finished products.
5. HEINDA has its own national test laboratory (Intertek Satellite Lab)to make sure the growth of our company.
FAQ
Q: What is the minimum quantity?
No MOQ,We can sell even 1PCS
Q: How long is the delivery time?
10 to 30 days, depending on your order quantity
Q: Can you send samples before placing the order?
Yes, sure. we can provide samples for quality checking.
Q: Do you provide OEM service?
Yes, we do
Q: How about the payment terms?
T/T,D/P,L/C,Paypal,Western union and cash all acceptable.
Q: How about your quality warranty?
When the products got problem during our warranty period, we will provide
