Auto Heavy Duty Door Closer
Model：CD-80Door Weight：Below 140 kg
Door Width：Below 1300mm
- Product Details
- PRODUCTS ADVANTAGE
Anhui Haida Door Control Equipment Co., Ltd. is one of the most experienced manufacturers and suppliers of auto heavy duty door closer in China. With abundant experience, we warmly welcome you to wholesale bulk high quality products in stock here and get free sample from our factory. Customized orders are welcome.
FEATURES
●The automatic door of this model is the 3rd generation single-opened one-way buried doors developed by our company
●With safety protection function(prevent the door from counterclockwise closing when it is blocked).
●They are characterized by small volume, low noise at running, easy installation, and stable performance, etc.
●It can be matched with manual remote control, sensor, button&other access device.
●The door is to be driven by the DC brushless motor, which has a long service life and responds rapidly. This is fully
embodied in the anti-trap function of the door.
SPECIFICATIONS
|
Model |
●CD-80 |
|
Applicable Door Width |
●Below 1300mm |
|
Applicable Door Weight |
●Below 140kg |
|
Automatic Door Opening Angle |
●80°~130° |
|
Opening Time |
●0 ~60 seconds adjustable |
|
Opening Speed |
●Adjustable from 3 to 6 seconds |
|
Closing Speed |
●Adjustable from 3 to 6 seconds |
|
Remote Control Function |
●Wireless password remote control open door, remote control often open door, remote control close and no open door |
|
Automatic Overload Protection |
●No |
|
Intelligent Obstacle Protection |
●Applied |
|
Alarm In Case Of Obstacles |
●Applied |
|
Intelligent Overheat Protection |
●Yes |
|
Door Closing Buffer Function |
●Yes |
|
Control Electric Lock Function |
●Adjustable |
|
Door Locking Force Adjustment Function |
●Yes |
|
Door Opening Buffer Function |
●Yes |
|
Connecting Rod Accessories |
●Slide rail or scissor arm optional |
|
Mounting Base Plate |
●Standard configuration |
|
Operation Damping Effect |
●No |
|
Electric Lock Function |
●Plug in lock or magnetic lock |
|
Safety and Anti Pinch |
●Rebound in case of resistance and infrared anti-pinch (an infrared anti-pinch is optional) |
|
Backup Power Function |
●2500ma lithium battery |
|
Power Supply |
●AC220V, AC14V/DC20V |
|
Input Function Static / Maximum |
●6W/45W |
|
Overall Dimension Of Main Engine |
●450x80x80mm |
Product Description
| 1. Equipped with manual remote control, the door can be opened at a long distance and can be used with a sensing or button, card reader, etc. |
| 2. The opening speed of the door can be adjusted and the stop state and dwell time of the door can be controlled arbitrarily. |
| 3. It is suitable for doors with internal and external opening structures, compatible with left-hand doors and right-hand doors, surface installation, and internal installation. |
| 4. The machine is driven by the DC brushless motor, which has a long service life and responds rapidly. This is fully embodied in the anti-trap function of the door. |
| 5. Multi-function interface and full-function remote control technology have the functions of double door interlock and position feedback. |
Why Choose Us
1. HAIDA has its own national test laboratory (Intertek Satellite Lab)to make sure the growth of our company.
2. Impeccable testing system covered raw material, components, and semi-finished products.
3. The factory has three production bases located in ZHEJIANG, ANHUI, and JIANGSU three provinces. The area covers 72,000 square meters.
4. The world's biggest floor spring manufacturer in China.Daily production of over 15,000PCS.
5. Over 33 years of producing experience. Ripe production process.
FAQ
Q: What is the minimum quantity?
No MOQ,We can sell even 1PCS.
Q: How long is the delivery time?
10 to 30 days, depending on your order quantity.
Q: Can you send samples before placing the order
Yes, sure. We can provide samples for quality checking.
Q: Do you provide OEM service?
Yes, we do.
Q: How about the payment terms?
T/T,D/P,L/C,Paypal,Western union and cash all acceptable.
Q: How about your quality warranty?
When the products got problem during our warranty period, we will provide.
