Maglev Automatic Sliding Door
Model：M300Opening range: 500-1050mm
Opening speed: 0.2-0.5m/s
- Product Details
- PRODUCTS ADVANTAGE
Anhui Haida Door Control Equipment Co., Ltd. is one of the most experienced manufacturers and suppliers of maglev automatic sliding door in China. With abundant experience, we warmly welcome you to wholesale bulk high quality products in stock here and get free sample from our factory. Customized orders are welcome.
FEATURES
Magnetic field generator
The controllable thrust is formed under the action of a controllable magnetic field and permanent magnetic field, and sharp force is formed to suspend the weight of the gate body
Microcomputer controller
High-performance control chip, realize perfect drive door body harmonious movement, realize everyone's personality idea of the operating system, is the perfect practitioner of human-computer interaction
control power supply
With over-power, over-voltage, short circuit,over-current,over-temperature, under voltage, over-voltage protection
The permanent magnet moving rail
High magnetic material is the guarantee of high efficiency
Function List
Manual function common function automatic full open single function automatic memory one dial full open hand pressure full open resistance reversal overload protection overheat alarm centralized control system lock door opening and closing speed adjustment door opening and closing holding time adjustment mobile phone Bluetooth app system
SPECIFICATIONS
Model | ● M300 |
Gantry Crane Height | ● 80mm |
Opening Range | ● 500-1050mm |
Opening Speed | ● 0.2-0.5m/s |
Door Opening Time | ● 0-30s |
Average Round Trip Power | ● 30w |
Width of Gantry Crane | ● 53.2mm |
Door Leaf Weight | ● 20-80KG |
Closing Speed | ● 0.2-0.5m/s |
Rated Power | ● 120w (Enhanced version 300w) |
Standard Configuration: | ● opening speed/Inching/Manual/One-way/Lock the door |
Personality Configuration: | ● Opening speed/Closing speed/All in one/Hand pressure fully open |
Standard Configuration List: | ● Aluminum moving rail aluminum cover drive unit main control unit Bluetooth module high-performance magnet power system load-bearing wheel suspension assembly |
WHY CHOOSE US
1. Many years of technical experience. The first induction door came out in 2003, with more than 16 years of technical experience
2. Longer after-sale protection. 1 years machine warranty, 2 years warranty on core components Our motor failure rate is 0.2%, and the controller failure rate is less than 0.1%
3. Longer after-sale protection. Super long service life Passed 2 million tests by CNAS National Testing Center
FAQ
Q: Are you a Manufacturer or a Trading company?
HEINDA is the manufacturer of doors & windows, Located in Jiangsu China. We also have factories in Zhejiang and Anhui. Welcome to our factory.
Q: Where is your company office and factory located?
A: Our offices and factories are located in the provinces of Zhejiang, Jiangsu and Anhui in China.
Q.What about your packages?
Our Packages are with foam, cartons, plywood cases. We also accept OEM.
Minimum Order Quantity (MOQ):
Quantity means a lot to the price, For the automatic door accessories, the MOQ can be negotiated.
Thanks for being interested in HEINDA products and services, Welcome to contact the HEINDA team if you need any assistance.
